Product Description
316 stainless steel also contains 2-3% molybdenum, in addition to iron, chromium and nickel. The addition of molybdenum significantly improves the performance of 316 stainless steel in certain corrosive environments, especially those containing chlorides. 316 stainless steel is more commonly used in situations requiring higher corrosion resistance.

316 stainless steel is preferred in the stainless industry due to a number of key reasons. Grade 316 is the standard molybdenum-bearing austenitic grade, which is highly resistant to pitting and crevice corrosion in chloride environments. So 316 stainless steel is more commonly used in situations where higher corrosion resistance is required. For example, in marine engineering, 316 stainless steel is often used to manufacture ship parts, subsea pipelines, offshore platforms and other facilities. In the chemical industry, it is also commonly used to manufacture equipment such as storage tanks, reactors and pipelines. In addition, in the medical field, 316 stainless steel is also widely used to manufacture medical devices and implants due to its excellent biocompatibility and corrosion resistance.


Product Parameters

Product Name316 Stainless Steel Plate
TypePlate
Thickness0.3mm-200mm
Length2000mm, 2438mm, 3000mm, 5800mm, 6000mm, 12000mm, etc.
Width40mm-600mm, 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc.
StandardASTM, AISI, JIS, GB, DIN, EN, etc.
SurfaceBA, 2B, NO.1, NO.4, 4K, HL, 8K, etc.
Scope of Application

Widely used in high temperature and electrical industry, medical equipment construction, chemical,

 food industry, agriculture and ship parts, food and beverage packaging,Kitchen supplies,

trains, airplanes, conveyor belts, vehicles, bolts, nuts, springs and screens, etc.

CertificateISO, SGS, BV, etc.
Production TechnologyHot Rolling, Cold Rolling
Edge ProcessingEdging, Trimming



Chemical Composition

CSiMnCrNiSPMo
≤ 0.03≤ 0.75≤ 2.016.0～18.010.0～14.0≤ 0.03≤ 0.0452.0～3.0



Mechanical Properties

Tensile Strength Kb (MPa)Yield Strength σ0.2 (MPa)Elongation D5 (%)Hardness
≥480≥177≥ 40≤ 187HB;≤ 90HRB;≤ 200HV



Physical Performance

Density(g/cm³)Modulus of Elasticity(Gpa)Coefficient of Thermal Expansion(10-6/°C)Coefficient of Thermal Conductivity(W/m*K)Resistivity(ΜΩ. cm)
7.9919316.016.274



Surface Selection

NameSurfaceFeaturesUse
Original SurfaceNO.1Silver whiteIndustrial tanks, chemical industry equipment, etc.,thicker by the mm-10.0mm of 3.0. Uses that do not require a surface gloss
Matte
Nlunt Surface2DSlightly shiny silvery whiteUsed for deep drawing processing, such as automobile components, water pipes, etc.General materials, deep drawing materials
Fog Surface2BSilver white with better gloss and flatness than 2D surface 0.39 micron roughnessSuch as tableware, building materials, etc.After surface treatment to improve mechanical properties, almost all applications are satisfied.
Frosted SurfaceNO.3Has a good gloss, with discontinuous roughUsed for building interior and exterior decoration materials,electrical products and kitchen equipment.
Frosted SurfaceNO.4Has a better gloss, with discontinuous rough, stripes than NO. 3 fineUsed for baths, building interior and exterior decoration materials,electrical products, kitchen equipment and food equipment.
Frosted SurfaceNO.240Has a better gloss, with discontinuous rough, stripes than NO. 4 fineUsed for bathroom, building interior and exterior decoration materials,electrical products, kitchen equipment and food equipment.
Frosted SurfaceNO.320Has a good gloss, with discontinuous roughBuilding Materials, Kitchenware
Frosted SurfaceNO.400Has a good gloss, with discontinuous roughBuilding materials, kitchen utensils, food equipment, etc.
Brushed SurfaceHLSilver gray with hairline stripes on the 2D or 2B product with the appropriate particle size abrasive material polished to make the surface continuous grinding patternMainly used in architectural decoration, elevators, building doors, panels, etc.
Bright SurfaceBAExcellent surface gloss with high reflectivityUsed for home appliances, mirrors, kitchen equipment, decorative materials, etc.
Mirror6KNot much worse than a mirror.Mirror, trim panel
Mirror8KLike a mirror.Mirror, trim panel




Product Show
